XG hanging cable clamp
Overview
Suspension clamp is mainly used for overhead power lines or substations, by connecting the wire to the wire, lightning line hanging on the insulator string will be suspended in the pole on the tower. Made of ferrous and aluminum alloy.
The meaning of the letter in the product model is:
X-Suspension Clamp G-Fixed S-Clamp U-U Screw J-Reinforced H-Aluminum Alloy F-Corona
K-on the bar T-Bags with A-head hanging plate B-with U-type hanging plate X-sagging
The hanging angle of the hanging wire clamp is not less than 8 times the diameter of the wire to be installed, and the percentage of the pulling force of the wire to the wire is not less than the value of the following table.
| Serial number | Category wire | Wire structure (aluminum steel ratio) | Percentage％ |
| 1 | ACSR | ＞ 1.7 | 14 |
| 4.0-4.5 | 18 | ||
| 5.0-6.5 | 20 | ||
| 7.0-8.0 | 22 | ||
| 11.0-20.0 | 24 | ||
| 2 | steel strand | (ultimate strength – 1176-1274N/mm) | 14 |
| 3 | Aluminum conductor | 24 |
